Repeatability

Better than 0.2%

Accuracy

Better than ±1% for flow velocity above 0.6ft/s

Flow Velocity

0~ ±32m/s

Display

2*20 backlit LCD(Chinese and English optional)Display instantaneous flow rate, accumulated flow rate(positive,
negative and net rates),velocity, time, analog inputs,etc.

operating

4*4 tactile keypad

Measuring Period

500m/s ( twice /s)

Signal Inputs

two channel three wire system PT100 platinum resistor input loop,to make heat meter has the function of displaying heat quantity. Three channel 4-20mA input optional,accuracy:0.1%,has the ability to input the signals of pressure, liquid level, temperature and so on.

signal output

One channel standard isolation RS485 output
One channel isolation 4-20mA or 0-20mA active output.
One channel OCT output(programmed between the pulse width(6-1000ms),default before leaving factory (200ms))
One channel isolation relay output,with positive,negative,net accumulation pulses and different alarm signals.

Communication Interface

RS-232,RS-485(optional)

protection level

mainframe:IP65, transducer:IP:68

Enclosure

Protection Class: IP65(NEMA 4X)
Explosive Proof Class: ExdⅡBT4(for model UFM-100F2B only)

Liquid Types

Virtually all commonly used liquids(full pipe)

Liquid Temp

32F~320F (0℃~160℃)

Pipe Size

 1"~240"(DN30~DN6000mm)tube size

Power
